V4 Granturismo: the undisputed protagonist In the Diavel philosophy, the engine is the fulcrum around which everything revolves: performance, character and style. That's why Ducati designers started with the V4 Granturismo, making it the star of all design elements, with the mechanics prominently displayed as a distinctive feature. Muscle-cruiser with supersport personality With a steel fuel tank with an animated, sculptural shape reminiscent of Ducati supersport bikes, the tail is light, slender and sharp. The air intakes are a breaking element in the side view, communicating all the muscular power. Character and uniqueness are found in the details The LED daytime running light at the front has a double-C shape. The rear light cluster consists of an array of point LEDs under the tail, with a highly original design that repeats the double C of the DRL and can not leave indifferent.
To request more details about this bike, simply enter your details below and one of our experienced sales team will get back to you.
Your enquiry has been recieved by a member of the Ducati Chelmsford team and they will get back to you within 24 hours
×To apply for finance on the Ducati Diavel V4, simply enter your details below and one of our experienced sales team will get back to you and discuss the various options available.
Your enquiry has been recieved by a member of the Ducati Chelmsford team and they will get back to you within 24 hours
×Frame
Frame
Tubular steel Trellis frame
Rake
27°
Front Wheel
Light alloy cast 3.5"x17"
Front Tyre
Pirelli Diablo Rosso III 120/70 ZR17
Rear Wheel
Light alloy casted 8.0"x17"
Rear Tyre
Pirelli Diablo Rosso III 240/45 ZR17
Fuel Tank Capacity
17l - (4.5 US gal)
Dry Weight
223 kg (492 lb)
Performance
Engine Type
Ducati Testastretta DVT 1262, L-Twin cylinder, 4 valves per cylinder, Dual Spark, Liquid cooled, Desmodromic Variable Timing
Displacement
1,262 cc (77.0 cu in)
Power
162 hp (119 kW) @ 9,500 rpm
Torque
129 Nm (95 lb-ft, 13.1 kgm) @ 7,500 rpm
Exhaust
Stainless steel pipes and single muffler with twin tail pipes, Catalytic converter and 2 lambda probes.
Gearbox Type
6 speed
Gearbox Ratio
1=37/15, 2=30/17, 3=27/20, 4=24/22, 5=23/24, 6=22/25
Primary Drive
Straight cut gears, ratio 1.84:1
Final Drive
Chain, Front sprocket Z15, Rear sprocket Z43
Clutch
Slipper and self-servo wet multiplate clutch with hydraulic control
Brakes
Front Brake
2 x Ø 320 mm semi-floating discs, Radially mounted Brembo monobloc 4-piston M4.32 callipers, PR18/19 radial master cylinder, Bosch Cornering ABS Evo
Rear Brake
Ø 265 mm disc, 2-piston Brembo floating calliper, Bosch Cornering ABS Evo
Suspension
Front Suspension
Ø 50 mm adjustable usd fork
Rear Suspension
Monoshock, preload and rebound adjustable, Aluminium casted single-sided swingarm
Dimensions
Wheelbase
1600mm (63 in)
Front Wheel Travel
120mm (4.7in)
Rear Wheel Travel
130mm (5.1in)
Seat Height
780 mm (30.7 in)
Bore x Stroke
106 x 71.5 mm
Compression Ratio
13.0 : 1
