Climb aboard and let fun take charge. The new Hypermotard 698 Mono is the first single-cylinder road-going Supermotard by Ducati, born with just one aim – to transmit excitement, dominating the scene. Simple, lightweight, and agile, it is a true “fun-bike” with racing DNA.
Style, power, and control. The ideal combo that leaves you with just one thought: to enjoy every moment aboard the Hypermotard 698 Mono.
A real Supermotard is a single-cylinder. And that's all there is to it. Simple, compact, slender, and aggressive. The design of the Hypermotard 698 Mono centre's around these elements, which marry with the sophisticated and clean lines for which every Ducati stands out.
Explore the collection dedicated to the Hypermotard 698 Mono. Flaunt an aggressive look, designed for those with personality to spare. And if you want to further customize your bike, choose Ducati Performance accessories, like the Termignoni racing exhaust, racing seat, and motard footpegs.
To request more details about this bike, simply enter your details below and one of our experienced sales team will get back to you.
Your enquiry has been recieved by a member of the Ducati Chelmsford team and they will get back to you within 24 hours
×To apply for finance on the Ducati Hypermotard 698 Mono, simply enter your details below and one of our experienced sales team will get back to you and discuss the various options available.
Your enquiry has been recieved by a member of the Ducati Chelmsford team and they will get back to you within 24 hours
×Frame
Frame
Tubular steel Trellis frame
Rake
26.1°
Front Wheel
Y shaped 5-spoke light alloy 3.5" x 17"
Front Tyre
Pirelli Diablo Rosso IV, 120/70 ZR17
Rear Wheel
Y shaped 5-spoke light alloy 5.0" x 17"
Rear Tyre
Pirelli Diablo Rosso IV, 160/60 ZR17
Fuel Tank Capacity
12 l (3 US gallons)
Performance
Engine Type
Superquadro Mono, single-cylinder, 4 valves per cylinder, Desmodromic timing, 2-balance countershafts, liquid cooled
Displacement
659 cc
Power
57 kW (77.5 hp) @ 9,750 rpm
Torque
63 Nm (46.5 lb-ft) @ 8,000 rpm
Exhaust
1-2 exhaust system, double aluminium mufflers, catalytic converter and lambda probe
Gearbox Type
6 speed
Gearbox Ratio
1=36/13 2=35/17 3=32/20 4=29/22 5=24/21 6=26/25
Primary Drive
Straight cut gears; Ratio 1.968:1
Final Drive
Chain 520; Front sprocket 15; Rear sprocket 42
Clutch
Slipper and self-servo wet multiplate clutch, hydraulic control
Brakes
Front Brake
Ø 330 mm aluminium flange disc, Brembo M4.32 caliper, radial pump with adjustable lever, with Bosch Cornering ABS
Rear Brake
Ø 245 mm disc, single piston floating caliper, with Bosch Cornering ABS
Suspension
Front Suspension
Ø 45 mm Marzocchi fully adjustable aluminium fork
Rear Suspension
Progressive linkage with Sachs fully adjustable monoshock. Aluminium double-sided swingarm
Dimensions
Wheelbase
1,443 mm (56.8 in)
Front Wheel Travel
215 mm (8.5 in)
Rear Wheel Travel
240 mm (9.4 in)
Seat Height
904 mm (35.6 in) 889 mm (35.0 in) with low seat accessory
Bore x Stroke
116 x 62.4 mm
Compression Ratio
13.1:1
