Frame

Aluminium alloy "Front Frame"

Rake

24,5°

Front Wheel

3-spokes forged aluminium alloy 3.50" x 17"

Front Tyre

Pirelli Diablo Rosso IV Corsa 120/70 ZR17

Rear Wheel

3-spokes forged aluminium alloy 6.00" x 17"

Rear Tyre

Pirelli Diablo Rosso IV Corsa 200/60 ZR17

Fuel Tank Capacity

16.5 l - 4.36 gallon (US)

Dry Weight

193 kg (425 lb)

Engine Type

Desmosedici Stradale 90° V4, rearward-rotating crankshaft, 4 Desmodromically actuated valves per cylinder, liquid cooled

Displacement

1,103 cc

Power

153 kW (208 hp) @ 13,000 rpm

Torque

123 Nm (90.4 lb-ft) @ 9,500 rpm

Exhaust

4-2-1-2 system, with 2 catalytic converters and 4 lambda probes

Gearbox Type

6 speed with Ducati Quick Shift (DQS) up/down EVO 2

Gearbox Ratio

1=38/14 2=36/17 3=33/19 4=32/21 5=30/22 6=30/24

Primary Drive

Straight cut gears; Ratio 1.80:1

Final Drive

Chain; Front sprocket 15; Rear sprocket 42

Clutch

Hydraulically controlled slipper and self-servo wet multiplate clutch. Self bleeding master cylinder

Front Brake

2 x 330 mm semi-floating discs, radially mounted Brembo Monobloc Stylema® (M4.30) 4-piston calipers with Cornering ABS EVO. Self bleeding master cylinder.

Rear Brake

245 mm disc, 2-piston caliper with Cornering ABS EVO

Front Suspension

Öhlins NIX30 43 mm fully adjustable fork with TiN treatment. Electronic compression and rebound damping adjustment with Öhlins Smart EC 2.0 event-based mode

Rear Suspension

Fully adjustable Ohlins TTX36 unit. Electronic compression and rebound damping adjustment with Öhlins Smart EC 2.0 event-based mode. Aluminium single-sided swingarm

Front Wheel Travel

120 mm (4.7 in)

Rear Wheel Travel

130 mm (5.1 in)

Seat Height

845 mm (33.3 in)

Bore x Stroke

81 x 53.5 mm

Compression Ratio

14.0:1
